How many microphone preamps does it have and what type are they?
It has four discrete, console-grade 6-transistor microphone preamps. They are located on combo XLR/jack inputs, with two of them also being Hi-Z compatible for connecting instruments directly.
What computer connectivity options are available?
The interface offers both Thunderbolt 3 (via USB-C) and USB 2.0 (via Type-B) connections, providing flexibility and ultra-low latency performance for compatible systems.
What effects are included and how are they processed?
It includes 37 analog-modelled effects, such as compressors, EQs, and preamps, with over 60 more available as optional expansions. All effects are processed in real-time by the onboard Synergy Core FPGA and DSP chips, putting zero load on your computer's CPU.
What digital audio formats does it support?
It supports sample rates from 44.1 kHz to 192 kHz. For digital connectivity, it has one ADAT input and output (supporting up to 8 channels) and one S/PDIF input and output.
How many headphone outputs are there and are they independent?
There are four independent stereo headphone outputs, each with its own level control. This allows you to create different monitor mixes for up to four performers simultaneously.
What is the dynamic range of the monitor outputs?
The monitor digital-to-analogue converters offer a dynamic range of 130 dB, providing exceptional clarity and detail for critical listening.
What is the unit's approximate size and weight?
The unit measures approximately 261 mm wide, 208 mm deep, and 44 mm high. It weighs 1.7 kg.
