What is included in the box?
The pedal unit itself is included. It requires a suitable 9V DC power adaptor (centre-negative), which is typically sold separately. A USB-C cable for connecting to computer software may also need to be purchased separately.
Can I use my own impulse response (IR) files?
Yes, the pedal has 12 empty slots dedicated for loading user impulse response files. These can be loaded via the USB-C connection using the free Amp Core Studio desktop application.
Does it have a headphone output?
Yes, it features a separate 6.3mm headphones output, making it suitable for silent practice or direct monitoring.
What type of power supply does it need?
It requires a standard 9V DC centre-negative power adaptor (like a typical pedalboard power supply) with a current rating of at least 120mA. It is not battery powered.
Is it compatible with MIDI?
Yes, it features programmable MIDI control via a 3.5mm TRS MIDI input/output jack, allowing for preset changes and parameter control from a MIDI controller or sequencer.
What are the physical dimensions?
The pedal measures 122mm in width, 72mm in depth, and 48mm in height, making it a compact unit for pedalboard use.
What audio connections does it have?
It features standard 6.3mm jacks for input, output, and send/return (for an effects loop). It also has a USB-C port for computer connection and a 3.5mm jack for MIDI.
